B-2990-FLWH4

Name: Widespread Faucet, Flex Lines, 5" Cast Spout, Wrist-Action Handles IDENTICAL TO B-2485
Brand: T&S Brass
Price: 505.00 USD
Availability: InStock

Widespread Faucet, Flex Lines, 5" Cast Spout, Wrist-Action Handles IDENTICAL TO B-2485

share this page Where to Buy

List Price $505.00

24" maximum concealed deck mount mixing faucet with brass body, polished chrome plated cast spout with 2.2 GPM aerator, compression cartridges with spring checks, flexible supplies, 4" wrist action handles, polishedchrome plated escutcheons and 1/2" NPT male inlets with coupling nuts. Certified to ASME A112.18.1/CSA B125.1, NSF 61-Section 9 and NSI 372. Meets ADA ANSI/ICC A117.1 requirements.

Nozzle Flow: 2.2 GPM (8.33 L/min)
Pressure Max: 125 psi (8.62 bar)
Pressure Min: 20 psi (1.38 bar)
Temperature Max: 140 F (60℃)
Temperature Min: 40 F (4.44℃)

Body: Adjustable Inlet
Body: Concealed
Body Mount: Deck
Cartridge-Spindle: 1/4 Turn Compression
Feature: Spring Check
Handle: 4 in Wrist (101.6 mm)
Inlet: 1/2 in NPSM Male
Inlet: Adjustable Centers
Material: Brass Construction
Nozzle: 5 in (127.0 mm)
Nozzle: Cast Spout
Nozzle Flow: 2.2 GPM (8.33 L/min)
Nozzle Outlet Type: Aerator
Pressure Max: 125 psi (8.62 bar)
Pressure Min: 20 psi (1.38 bar)
Temperature Max: 140 F (60℃)
Temperature Min: 40 F (4.44℃)

Certifications

ASME A112.18.1 / CSA B125.1
Buy American Act (BAA)
NSF/ANSI 372 (Lead Content)
NSF/ANSI/CAN 61 Q≤1

Compliances

ANSI A117.1 (ADA)

Box Dimensions: 3.75 x 10.25 x 15.44
Weight: 7.40 lbs (3.36 kg)
UPC: 671262561891

California Prop #65 Warning

California Prop #65 Warning

WARNING

California Proposition 65

WARNING: This product can expose you to chemicals including Lead, Chromium (hexavalent compounds) and Phthalates (DEHP) which are known to the State of California to cause cancer and birth defects or other reproductive harm.

For more information, please go to www.P65Warnings.ca.gov.

Related Literature

Resources

Spec Drawings/Parts Explosion

Submittal

Warranty: One Year (Limited)

Installation Instructions

Concealed Widespread Fct.

Accessories

B-0898-OF

Grid Drain Assembly, Offset, Polished Chrome

B-2990-FLWH4

Widespread Faucet, Flex Lines, 5" Cast Spout, Wrist-Action Handles IDENTICAL TO B-2485

List Price $505.00

Nozzle Flow: 2.2 GPM (8.33 L/min)

Pressure Max: 125 psi (8.62 bar)

Pressure Min: 20 psi (1.38 bar)

Temperature Max: 140 F (60℃)

Temperature Min: 40 F (4.44℃)

Body: Adjustable Inlet

Body: Concealed

Body Mount: Deck

Cartridge-Spindle: 1/4 Turn Compression

Feature: Spring Check

Handle: 4 in Wrist (101.6 mm)

Inlet: 1/2 in NPSM Male

Inlet: Adjustable Centers

Material: Brass Construction

Nozzle: 5 in (127.0 mm)

Nozzle: Cast Spout

Nozzle Flow: 2.2 GPM (8.33 L/min)

Nozzle Outlet Type: Aerator

Pressure Max: 125 psi (8.62 bar)

Pressure Min: 20 psi (1.38 bar)

Temperature Max: 140 F (60℃)

Temperature Min: 40 F (4.44℃)
